This review dives deep into the ELFHUB 12V 100Ah LiFePO4 battery, examining its performance and safety features to determine if it lives up to the hype. We unpack the battery's arrival, initial inspection, and included documentation, providing a detailed account of its build quality and pre-shipment condition. The review then moves into rigorous testing, covering capacity measurements under various load conditions, including high-amperage draws pushing the battery's limits. Safety features, such as low-temperature charging protection, are thoroughly assessed.Ultimately, this comprehensive evaluation assesses the ELFHUB battery's real-world performance against its advertised specifications. We explore the accuracy of its claimed capacity and delve into the effectiveness of its safety mechanisms. The findings will help potential buyers make an informed decision, weighing the battery's pros and cons to see if it's the right choice for their power needs. The conclusion provides a clear verdict on whether the ELFHUB 12V 100Ah LiFePO4 battery is a worthy investment.
Pros And Cons
- Passed all tests, including high amperage protection test.
- Has a 100 amp continuous discharge rating.
- Shuts off when exceeding 150-160 amps.
- Has a 400 amp surge capacity (for approximately 1 second).
- Includes Bluetooth app for monitoring.
- Has low temperature charging protection.
- Capacity test showed 102-103 amp-hours.
- The stated nominal voltage (12V) is incorrect; it should be 12.8V.
- The specified energy amount (1200 Watt-hours) is incorrect; it should be 1280 Watt-hours.
Read more: OUKITEL P2001 PLUS Review: Best Budget Portable Power Station?
Unboxing and Initial Impressions
The ELFHUB 12V 100Ah LiFePO4 battery arrived in a standard package. Inside, I found a user manual, a Bluetooth pairing guide, and the battery itself nestled securely in protective Styrofoam. The battery's exterior is simple, all black with minimal branding and key specifications printed on the side. First impressions were positive, with a solid build quality evident even before testing.
The included documentation was clear and concise, providing straightforward instructions for Bluetooth connection and battery operation. A quick voltage check revealed a reading of 13.17V, indicating a healthy pre-shipment charge level. This is crucial to ensure battery longevity and prevent potential issues.
Specifications and Capacity Test
The ELFHUB battery is a Group 24 format, slightly smaller than a Group 31, weighing approximately 22.8 lbs. While the label states a nominal voltage of 12V, this is incorrect for LiFePO4 batteries; it should be 12.8V. This discrepancy affects the stated energy capacity (1200Wh vs the accurate 1280Wh).
I performed a capacity test using a 20A LiFePO4 charger. The results were impressive, showing approximately 85% of the advertised 100Ah capacity. The initial 12.77% drop within the first 5 hours points to an overall slight underperformance compared to claimed 100Ah specification; however, the battery still delivered a significant portion of rated capacity.
High Amperage Testing
The high amperage test involved pushing the battery to its limits. The test setup included a 5000W inverter, a heat gun, a cooktop, and a griddle, aiming to draw up to 400A. Initially, I tested with a continuous 100A load for 5 minutes, which the battery handled without issue, maintaining a voltage of 12.42V from the initial 13.39V.
Incrementally increasing the load showed the battery's protective features in action. At approximately 200A, the battery’s safety mechanisms triggered, resulting in a power shutdown. This is crucial to protect the battery and prevent damage. Even under high loads, the battery quickly recovers upon load reduction.
A final test used a high-draw power tool, resulting in a measured 399.4A surge before shutdown. This confirms the battery's 400A surge capacity, but as expected for a surge rating, it's only sustainable for a very short period.
Low Temperature Charging Protection Test
The low-temperature charging protection was tested by placing the battery in a cooler set to 30°F for 24 hours. Using the Bluetooth app, I monitored the battery's temperature, confirming it reached the threshold where charging should be prevented.
After 24 hours, the battery was connected to a 20A LiFePO4 charger. The charger initially showed a charging indication, but quickly switched to a ‘standby’ state within seconds, demonstrating that the low-temperature protection successfully prevented charging at low temperatures. The app also confirmed this by displaying low-temp protection status.
This test confirmed the battery's built-in cold-weather protections, preventing damage from attempting a charge at sub-freezing temperatures.
Conclusion and Verdict
The ELFHUB 12V 100Ah LiFePO4 battery exceeded expectations in almost every aspect. It consistently delivered impressive performance under various load tests, accurately responding with safety shutdowns at higher amperages.
The integrated Bluetooth app provides valuable real-time monitoring and diagnostic capabilities. The inclusion of low-temperature charging protection adds an extra layer of safety and longevity. While the capacity test revealed a slight underperformance (around 85% of advertised capacity), the overall performance and safety features make this a worthwhile battery option.
For those seeking a reliable, high-capacity LiFePO4 battery with advanced safety features and convenient Bluetooth monitoring, the ELFHUB battery is a strong contender. Its price point, combined with its excellent performance and safety features makes it a very competitive choice.
